Specifications:

Display: 5 digit, 0.39 inch 7 segment led display

Charcter height: 10mm (0.39 inch)

Outer dimensions: 49*12.9*7.3 mm

white segments black surface

With common anode

Emitting color: super bright red

Luminous intensity: 50-60 mcd

Forward voltage: 1.8-2.2V/led

Forward current:5-10mA/led

Colors: red, blue, yellow green, pure green, amber, orange and pure white

Absolute Maximum Ratings(Ta=25ºC)

Code:Amber/Yellow -Y

Code:Orange -F

Code:Super Bright Red -R

Code:Ultra Bright Red -UR

Code:Pure Green -G

Code:Ultra Bright Blue -BH

Code:Ultra Bright White -WH

Feature of Segment LED Displays

--White segment Black surface

--High luminous intensity

--Low current operation

--Stable performance

--Continuous uniform segments

--Easy mounting on PCB

--IC compatible

--RoHS compliant

Quick Detail of Segment LED Displays

1. We can supply you all kinds of 7 segment LED display:

--- Digit size: from 0.25" to 20"

--- Digit Numer: 1, 2, 3, 4, 5 and 6 digits

2. Segment : 7 segment,14segment and16 segment both available

3. Available Emitting color: Red, Yellow-green,green, blue, yellow, pink, white, bi-color

4. Available surface color: black,gray or red
